No HIDPI timeline in macOS

This initially didn’t bother me as much, but after cutting a clip in half, I was not able to see the cut.

See for yourself (screenshot): https://0x0.st/onsG.jpeg

I discovered a thread where someone got HIDPI working, but I’m unable to apply the same fix/workaround in Ardour 7.1 on macOS.
Thread: high resolution displays - #7 by blubee

Seeing that it works, I suspect I need to configure something…

Occurs on macOS Ventura aarch64 / screen resolution 3024 x 1964

Interesting thing I found that may be related:
When I run Neofetch it reports a resolution that is a quater of the original (1512x982)

Does not seem to be apparent on Harrison-Mixbus in this Video.
However, I tried the demo, and it’s there visible too.
Maybe specific to Ventura :frowning:

I don’t think ardour is compiled for Ventura, think it was big sur.

The application wide zoom options are only available on Windows and Linux. On macOS, apple libraries scaling the application automagically per screen (not per application).

Ardour’s editor canvas is intentional exempt from Retina scaling (each pixel will become a 2x2 block for performance reasons). The mixer and everything else however are rendered wit HiDPI resolution.

You can force the editor to scale by setting an environment variable.

ARDOUR_BUNDLED=1 ARDOUR_NSGL=0 /Applications/Ardour.app/Contents/MacOS/Ardour7

The Variables don’t seem to have any effect.
Except that antialiasing kicks in if ARDOUR_NSGL is set to 1.

Is there an explanation somewhere on what those variables do?

ARDOUR_NSGL=0 disables using openGL (an NSOpenGLContext).

By default NSGL is enabled and the editor is rendered in software onto an openGL texture. This sidesteps Apple’s color-correction which is rather expensive and slows down rendering the editor on some systems (Reaper uses the same trick Justin Frankel - main feed).

Without an intermediate GL surface, the editor is rendered like the rest of Ardour, directly onto an Apple NSView (which scales automatically).

(ARDOUR_BUNDLED=1 is needed to launch Ardour from a terminal, and make Ardour believe that you opened the .app application bundle with all resources below Content/).
